TRX ELCW Weatherproof Switch Socket 250V IP55 Modular 1–4 Gang

Hover to inspect · click to zoom. Product shown may differ from the configured reference. Passa il mouse per ispezionare · clicca per ingrandire. Il prodotto mostrato può differire dalla referenza configurata.

Waterproof SocketPrese Stagne

TRX ELCW Weatherproof Switch Socket 250V IP55 Modular 1–4 GangTRX ELCW Weatherproof INTERRUTTORE PRESA 250V IP55 Modular 1–4 Gang

ReferenceReferenza ELCW-250V IP55
IP55 13–13A
In production · made to order In produzione · su ordinazione
Weatherproof socket outlets provide sealed, IP55/IP66-rated general power points for use in exposed or washdown locations, available in modular multi-gang configurations.
Request a quoteRichiedi un preventivo Dimensions & wiringDimensioni e cablaggio

Dimensions & wiringDimensioni e cablaggio

TRX ELCW Weatherproof Switch Socket 250V IP55 Modular 1–4 Gang — dimensional drawing

Model selection matrixMatrice di selezione modello

Every reference in this family, compared on the specifications that differ. The highlighted row is the product shown above. Voltage colour follows the CEE code moulded into the housing. Tutte le referenze di questa famiglia, confrontate sulle specifiche che variano. La riga evidenziata è il prodotto mostrato sopra. Il colore della tensione segue il codice CEE stampato sull'involucro.

110V 230V 400V 500V otheraltro
ReferenceReferenza Rated currentCorrente nominale PolesPoli ProtectionProtezione VoltageTensione Link
ELCW-250V IP55 this modelquesto modello 13A Single pole single throw (SPST) IP55 250V
SO56-3P250V-10A-IP66 10A null IP66 250V ViewVedi
SO56-3R250V-20A-IP66 20A null IP66 250V 500V ViewVedi
SO56-5R250V-50A-IP66 50A null IP66 250V ViewVedi

Key featuresCaratteristiche chiave

  • IP55/IP66 sealed body Guards against dust and water ingress.
  • Modular gang options 1 to 4-gang configurations available.
  • Standard pin geometry Compatible with common plug types.
  • Durable outdoor housing UV and impact resistant enclosure.

ApplicationsApplicazioni

  • Outdoor work areas Exposed general-purpose power points.
  • Washdown & wet locations Processing areas requiring frequent cleaning.
  • Site cabins & compounds General power distribution.
  • Agricultural buildings Damp and dusty environment power outlets.
